ELECTRONIC DEVICE FAILURE ANALYSIS | VOLUME 19 NO. 1

A SUMMARY OF THE ISTFA 2016 PANEL DISCUSSION:

NEXT GENERATION OF FA ENGINEER

Frank Altmann

Fraunhofer IMWS, Halle, Germany

frank.altmann@fraunhofer.imws.de

EDFAAO (2017) 1:33-34

1537-0755/$19.00 ©ASM International

®

A

failure analysis (FA) engineer’s core business is to

investigate and solve reliability problems of tech-

nologies for electronic applications by identifying

process variations and root causes of defects and by sug-

gesting corrective actions. An FA engineer must handle

multiple FA techniques for defect localization, prepara-

tion, and physical analysis with continuously increasing

complexity. In parallel, he needs sophisticated skills in

communication because he often acts as an intermedi-

ary between different parties (fab, design, test, customer,

etc.). Under theseaspects, the ISTFA2016Panel Discussion

was dedicated to the following topics:

• Howis a typical FA laborganized?Whichskills and levels

of education are required for a future FA engineer?

• How does one go from being a specialist in a certain

preparation or analysis method to being an experi-

enced FA engineer ready for customer meetings?

• Which internal/external trainingprograms are available

(face-to-face or online)?

• Where does the money and time come from that is

spent to become trained in FA?

The panel members were Professor Christian Boit,

Technische Universität Berlin; James Cargo, Broadcom

Ltd.; and Nebojša Janković, NXP Semiconductors. Each

panel member has a long history of experience in FAwork,

education, training, and lab management.

The Panel Discussion was introduced by Nebojša

Janković. He pointed out that a typical FA lab is orga-

nized by FA engineers as job owners being responsible

for performing hands-on electrical FA and physical char-

acterization, with the emphasis on software- and

hardware-based device fault localization. Only highly spe-

cialized investigations are done by dedicated engineers.

Standardized physical analysis steps are mostly done by

a technician crew. Strong preference should be given to

mixed-signal IC design, test, and layout understanding.

Furthermore, an FA engineer should have experiencewith

memory devices, especially nonvolatile options, as well

as reverse engineering skills, including ICprocess technol-

ogy knowledge. Responsibilities should include not only

the use of existing and available equipment, techniques,

and methods but also the development of new methods

and techniques. An FA engineer should be able to work

independently but also to cooperate with peer product,

test, design, and process engineers as well as customers.

In addition to technical skills, hemust also be a good team

player. AnFAengineer shouldbeeducated to theacademic

level of a Master’s or Ph.D. degree in technical sciences

and then must seek continuous learning and training.

With the experience and routine from internal customer

meetings, he also strengthens the communication skills

necessary to take care of end-customers’ needs. This can

be managed by additional coaching and mentoring on

the job, focused on having an outside view and an end-

customer’s perspective. A typical beginner learns the first

skills and tools internally on the job, beingmentored and

trained by an experienced FA engineer. External courses

must follow for certain specialized methods and tools.

After the introduction, an intense open discussion

began between the panelists and the audience. It was

discussed that FA spans a large breadth of topics and

educational disciplines, and almost no undergradu-

ate programs are available at universities. Linking to

“AN FA ENGINEER SHOULD BE EDUCATED

TO THE ACADEMIC LEVEL OF A MASTER'S

OR Ph.D. DEGREE IN TECHNICAL

SCIENCES AND THEN MUST SEEK

CONTINUOUS LEARNING AND TRAINING.”
