FIB cross sectioning and ionmilling. The presentation was

concludedwith a case study involving a T0 package failure,

where the package FA flow, involving a few state-of-the-art

FA toolsets, was followed. The summary highlighted the

growing importance of 3-D x-ray for FA turnaround-time

reduction on complex packages as well as plasma FIB for

successful package preparation.

Power semiconductor sample-preparation trends in

relation to advances in semiconductor architecture and

advanced power package design and materials were dis-

cussed next. Ian Kearney of Texas Instruments presented

“General Power MOSFET/3-D Stacked Die Sample Prep.”

He gave an overviewof the popular industry FA techniques

used on discretes and integrated power devices.

Ian presented various package polishing techniques

and discussed a few FA case studies involving discrete

and integrated power chip-scale package/land grid array

and 3-D stacked-dice packaged devices. The case studies

highlighted package FA challenges involving solder voiding

and solder profiling, wire sag isolation, solder cracking,

and 3-D multichip-module package decapsulation after

temperature cycling (MIP), to name a few.

After the presentations, the session continued with a

question-and-answer panel discussion. Several involved

conversations took place among the User Group attend-

ees and the panelists about sample-prep challenges and

limitations and the opportunities for future trends and

directions. Several discussions continued after the session

was over. Many thanks to all the participants who stayed

until the very end, and special thanks to Digit Concept for

their support.

A

large number of presenters covered a broad spec-

trumon topics surrounding nanoprobing during the

Nanoprobing User Group.

Sweta Pendyala of Globalfoundries started the presen-

tations and addressed how to reduce the time it takes for

nanoprobing to localize a defect. Localization techniques

such as scanning electronmicroscopy (SEM)-based voltage

contrast and atomic forcemicroscopy (AFM)-based current

imaging have been employed to localize defects on bulk

semiconductor technology. These techniques cannot be

used “as is” for localizing defects on silicon-on-insulator

(SOI) technology because there is no direct path to ground

from the SOI to the sample chuck. Two different atomic

force probe (AFP)-based localization techniques have

been successfully implemented to localize defects on SOI

technology. The first technique is capacitance-based top-

down scanning capacitance localization. In this technique,

a low-frequency alternating current signal on the substrate

causes a change in capacitance. The amplitude of the

signal indicates the amount of dopant and the phase type

of dopant. Using a reference part, scanning capacitance

can pinpoint the defect area, and then nanoprobing can

be performed there. The second technique is a current-

imaging-based picocurrent localization technique that

has been modified to localize defects on SOI. The AFP

provides a current map, and, in SOI, the path to ground

ISTFA 2015 NANOPROBING USER GROUP

Moderators: John Sanders, DCG Systems, and Nicholas Antoniou, ReVera, Inc.

john_sanders@dcgsystems.com NAntoniou@revera.com

can be provided through the part by using the defect as

a detector. For example, one can bias the ground rail and

ground V

dd

. In summary, scanning capacitance can be used

on SOI and is highly sensitive but can cause false positives.

Picocurrent localization needs a path to ground, but if one

can be found, it rarely gives a false positive.

Two questions were asked by the audience:

• What is the tolerance of the topography? Answer: 15

to 20 nm

• What is the typical raster time? Answer: 2 min

Vinod Narang of AMD Singapore presented the failure

analysis for advancedmicroprocessors. Soft fails, in which

an SRAM bit cell exhibits voltage sensitivity, are difficult to

analyze. In this work, SEM-based nanoprobing followed

by transmission electron microscopy (TEM) was shown

to successfully identify the root cause of the failure. The

work also highlights that collaboration is needed with

design teams to simulate the fails. This helps to explain

the nanoprobing andphysical failure analysis observations

to further confirm and validate the findings. A case study

was presented for a built-in self-test soft failure, an SRAM

double bit that failed at high voltage and high tempera-

ture. By probing each transistor in the SRAM cell, a single

transistor was found with low I

dsat

. A cross-sectional TEM

image of the gate did not explain this failure. By tilting the

S - 7
