Delays in Focused Ion Beam [FIB] Circuit Edit,”
J.
Vac. Sci. Technol. B,
2015,
33
, p. 012203.
• J.L.M. Oosthoek, R.W. Schuitema, G.H. ten Brink, et al.:
“ChargeCollectionMicroscopy of In-SituSwitchable
PRAM Line Cells in a Scanning Electron Microscope:
TechniqueDevelopment andUniqueObservations,”
Rev. Sci. Instrum.,
2015,
86
, p. 033702.
• L. Rigutti, L. Mancini, D. Hernández-Maldonado, et al.:
“Statistical Correction of Atom Probe Tomography
[APT] Data of Semiconductor Alloys Combinedwith
Optical Spectroscopy: The Case of Al
0.25
Ga
0.75
N,”
J.
Appl. Phys.,
2016,
119
, p. 105704.
• A. Sabouri, C.J. Anthony, P.D. Prewett, et al.:
“Effects
of Current on Early Stages of Focused Ion Beam
[FIB] Nano-Machining,”
Mater. Res. Express,
2015,
2
, p. 055005.
• N. Shibata, S.D. Findlay, H. Sasaki, et al.:
“Imaging of
Built-In Electric Field at a
p-n
Junction by Scanning
Transmission Electron Microscopy [STEM],”
Sci.
Rep.,
2015,
5
, p. 10040.
• D.D. Wang, Y.M. Huang, P.K. Tan, et al.:
“Two Planar
[High Precision] Polishing Methods by Using FIB
Technique: Toward Ultimate Top-Down Delayering
for Failure Analysis,”
AIP Adv.,
2015,
5
, p. 127101.
• Y.J. Xiao, F.Z. Fang, Z.W. Xu, and X.T. Hu:
“Annealing
Recovery of Nanoscale Silicon Surface Damage
Caused by Ga Focused Ion Beam [FIB],”
Appl. Surf.
Sci.,
2015,
343
, p. 56.
• R. Xu, C.C. Chen, L. Wu, et al.:
“Three-Dimensional
Coordinates of Individual Atoms in Materials
Revealed by Electron Tomography,”
Nat. Mater.,
2015,
14
, p. 1099.
• J. Yamauchi, Y. Yoshimoto, and Y. Suwa:
“X-Ray
Photoelectron Spectroscopy Analysis of Boron
Defects in Silicon Crystal: A First-Principles Study,”
J. Appl. Phys.,
2016,
119
, p. 175704.
• T. Yamazaki, T. Kato, T. Uemura, et al.:
“Origin Analysis
of Thermal Neutron Soft Error Rate at Nanometer
Scale,”
J. Vac. Sci. Technol. B,
2015,
33
, p. 020604.
• B. Zhang, D.F. Gardner, M.D. Seaberg, et al.:
“High
Contrast 3-D [X-Ray] Imaging of Surfaces near
the Wavelength Limit Using Tabletop EUV
Ptychography,”
Ultramicroscopy,
2015,
158
, p 98.
