failure mechanisms exhibit improved SERs with similar
magnitudes. The authors have shown that these reduced
error rates result from a reduction in charge collection
due to the limited silicon geometry of the fin structure.
Multicell errors are determinedby charge sharing between
physically adjacent SRAM bit cells. Importantly, it was
found that MCU probabilities at a given cluster length of
bit cells decrease significantly with technology progres-
sion, and this is also primarily a result of the decrease in
charge collection inherent in the FinFET.
REFERENCES
1. D.D. Lu et al.: “A Multi-Gate MOSFET Compact Model Featuring
Independent-Gate Operation,”
Proc. Int. Electron Dev. Meet.,
2007,
pp. 565-68.
2. T. Park et al.: “Fabrication of Body-Tied FinFETs (Omega MOSFETs)
Using Bulk Si Wafers,”
Proc. Symp. VLSI Technol. Digest Technol.
Papers,
2003, pp. 135-36.
3. C.R. Manoj, N. Meenakshi, V. Dhanya, and V. Ramgopal Rao: “Device
Optimization of Bulk FinFETs and Its Comparison with SOI FinFETs,”
Proc. Int. Workshop Phys. Semicond. Dev.,
2007, pp. 134-37.
4. C. Ma et al.: “A Unified FinFET Reliability Model Including High k
Gate Stack Dynamic Threshold Voltage, Hot Carrier Injection, and
Negative Bias Temperature Instability,”
Proc. Qual. Electron. Des.,
2009, pp. 7-12.
5. T. May andM. Woods: “Alpha-Particle-Induced SoftErrors inDynamic
Memories,”
IEEE Trans. Electron Dev.,
Jan. 1979,
ED-26,
pp. 2-9.
6. J.F. Ziegler and W.A. Lanford: “Effect of Cosmic Rays on Computer
Memories,”
Science,
Nov. 1979,
206
(4420), pp. 776-88.
7. R.C. Baumann and E.B. Smith: “Neutron-Induced Boron Fission as a
Major Source of Soft Errors in Deep Submicron SRAMDevices,”
Proc.
IEEE 38th Ann. Int. Reliab. Phys. Symp.,
2000, pp. 152-57.
8. S.-J. Wen, S.Y. Pai, R. Wong, M. Romain, and N. Tam: “B
10
Findings
and Correlation to Thermal Neutron Soft Error Rate Sensitivity for
SRAMs in the Sub-Micron Technology,”
IEEE
Integr. Reliab. Workshop
(IIRW),
2010, pp. 31-33.
9. Y.-P. Fang and A.S. Oates: “Thermal Neutron-Induced Soft Errors in
AdvancedMemory and Logic Devices,”
IEEE Trans. Dev. Mater. Reliab.,
March 2014,
14
(1), pp. 583-86.
10. Y.-P. Fang and A.S. Oates: “Muon-Induced SoftErrors in SRAMCircuits
in the Terrestrial Environment,”
IEEE Trans. Dev. Mater. Reliab.,
March
2015,
15
(1), pp. 115-22.
11. JEDEC Test Standard 89,
jedec.org.
12. “The ANITA Neutron Beam Facility,” The Svedberg Laboratory,
Uppsala University,
tsl.uu.se/irradiation-facilities-tsl/ ANITA_neutron_beam_facility/.13. Laboratoire Léon Brillouin, France,
www-llb.cea.fr/en/.14. Y.-P. Fang and A.S. Oates: “Neutron-Induced Charge Collection
Simulation of Bulk FinFET SRAMs Compared to Planar SRAMs
,” IEEE
Trans. Dev. Mater. Reliab.,
Dec. 2011,
11
(4), pp. 551-54.
15. G. Hubert, J.-M. Palau, K. Castellani-Coulie, M.-C. Calvet, and
S. Fourtine: “Detailed Analysis of Secondary Ions’ Effect for the
Calculation of Neutron-Induced SER in SRAMs,”
IEEE Trans. Nucl.
Sci.,
2001, pp. 1953-59.
16. Y.P. Fang and A.S. Oates,
IEEE Trans. Dev. Mater. Reliab.,
2016, in press.
17. F. Gimiz, J.A. Lopez-Villanueva, J.B. Roldin, and J.E. Carceller:
“Influence of the Doping Profile on Electron Mobility in a MOSFET,”
IEEE Trans. Electron Dev.,
Nov. 1996,
43
(11), pp. 2023-25.
18. G. Kaiblinger-Grujin, H. Kosina, and S. Selberherr: “Influence of the
Doping Element on the Electron Mobility in
n
-Silicon,”
J. Appl. Phys.,
March 1998,
83
(6), pp. 3096-101.
19. G. Masetti, M. Severi, and S. Solmi, “Modeling of Carrier Mobility
against Carrier Concentration in Arsenic-, Phosphorus-, and Boron-
Doped Silicon,”
IEEE Trans. Electron Dev.,
1983,
ED-30
(7), pp. 764-69.
ABOUT THE AUTHORS
Anthony S. Oates
received a Ph.D. degree in physics from the University of Reading, Reading,
U.K., in 1985. He was then with AT&T Bell Laboratories, where his research centered on studies of
failure mechanisms in CMOS technologies. During this time, he was appointed as a Distinguished
Member of the Technical Staff, and he assumed responsibility for reliability physics development and
CMOS technology process quali cation. Since 2002, Dr. Oates has been with Taiwan Semiconductor
Manufacturing Company, Ltd., Hsinchu, Taiwan, where he is responsible for technology reliability
physics research and holds the position of Fellow of the TSMC academy. He has published more than
100 papers in the eld of microelectronics reliability, and he is the co-holder of seven patents. Dr. Oates is a Fellow of the
IEEE. He is currently the Editor-in-Chief for
IEEE Transactions of Device and Materials Reliability
. He served as the General
Chair of the International Reliability Physics Symposium in 2001 and was the chair of the IEEE Electron Devices Society
Device Reliability Advisory Committee from 2006 to 2011.
Yi-Pin Fang
receivedM.S. andPh.D. degrees inphysics fromNational TsingHuaUniversity, Hsinchu,
Taiwan, in 2000 and 2005, respectively. In 2005, he joined TSMC Hsinchu as a principal engineer; he is
currently a technical manager in the Technology Reliability Physics Department. Dr. Fang is responsible
for the analyses of soft-error-rate reliability issues. His research interests include cell-level soft-error-
rate model setup and TCAD simulations of ion-induced charge collection on devices.
